Curtain Wall
|
There are certain performance and aesthetic criteria that can only be achieved with a true full–depth monumental curtain wall. Whether the architect desires a dissociative projection between the facade elements and the slab structure, or the depth and grace of a single lite of floor-to-floor vision glass and shadow boxing, RWW’s curtain wall allows options for dozens of bespoke slab-masking configurations. Whether measuring by performance capabilities or aesthetic quality and expression, RWW’s curtain wall delivers in all conceivable ways. |
|
Operable Air Infiltration |
0.10 CFM/SQ.FT. @6.24 PSF |
|
Fixed Air Infiltration |
0.06 CFM/SQ.FT. @6.24 PSF |
|
Water Performance |
15 PSF |
|
CRF |
58 - 72 |
|
NFRC U-Factor |
0.29 - 0.46 BTU/hr·ft2·ºF |
|
Frame Depth |
7", 8", 9", & 11" |
|
Frame Sightline |
3" & 3.5" |
|
STC |
31 - 45 |
|
OITC |
29 - 38 |
|
8000 Series Brochure |
|
8000 Series Technical Details |
